Printer specifications1.Printing method: Thermal sensitive type
2.Printing instruction: Compatible with ESC/POS commands
3.Print resolution: 203 DPI
4.Printing speed: 180mm/s
5.Print width: 48/72mm
6.Print head temperature detection: Thermistor
7.Print head position detection: Microswitch
8.Paper presence detection: Reflective sensor
9.Reminder for Unclaimed Orders：Yes
10.Memory (this is a variable item and will not be publicly announced): FLASH: 256K
11.Press key：Paper advance key
12.USB port specification: USB 2.0 Type-C
13.USB VID PID VID:0471 PID:0055
Barcode character graphics
1.Graphic: Supports printing of bitmaps of different densities
2.One-dimensional code / QR code: UPC-A/UPC-E/JAN13 (EAN13)/JAN8 (EAN8)/ITF/CODABAR/CODE39/CODE93/ CODE128/QRCODE
3.Extended character set:
PC437(Std.Europe）/Katakana/PC850(Multilingual)/PC860(Portugal)/PC863（Canadian）/PC865(Nordic)/(West Europe)/(Greek)/(Hebrew)/(East Europe)/(Iran)/(WPC1252)/PC866(Cyrillic#2)/PC852(Latin2)/PC858/(IranII)/(Latvian)/(Arabic)/Pt151，1251/(PC747)/(WPC1257)/(Vietnam)/(PC864)/(PC1001)/(Uigur)/(Hebrew)/WPC1255(Israel)/PC720(Arabic)/WPC1256(Arabic)/WPC1257(N)/Armenian/PC857(Turkish)/WPC1254(Turkish)/Viscii/Georgia(Thai)/PC437(STD.Europe）/(Katakana)/PC437(STD.Europe）/PC858(Multilingual)/PC852(Latin-2)/PC860(Portuguese)/PC861(Icelandic)/PC863(Canadian)/PC865(Nordic)/PC866(Russian)/PC855(Bulgarian)/PC857(Turkey)/PC862(Hebrew)/PC864(Arabic)/PC737(Greek)/PC851(Greek)/PC869(Greek)/PC928(Greek)/PC772(Lithuanian)/PC774(Lithuanian)/PC874(Thai)/WPC1252(Latin-1)/WPC1250(Latin-2)/WPC1251(Cyrillic)/PC3840(IBM-Eussian)/PC3841(Gost)/PC3843(Polish)/PC3844(CS2)/PC3845(Hungarian)/PC3846(Turkish)/PC3847(Brazil-abnt)/PC3848(Brazil-ABICOMP)/PC1001(Arabic)/PC2001(lithuanian-KBL)/PC3001(Estonian-1)PC3002(Estonian-2)/PC3011(Latvian-1)/PC3012(Latcian-2)/PC3021(Bulgarian)/PC3041(Maltese)4.Character enlargement/rotation: Can be enlarged by 1 to 8 times in both horizontal and vertical directions, and can be rotated for printing or printed upside down.
5.Paper type: Thermal roll paper
6.Character set:Standard configuration: Simplified Chinese GB18030, Traditional Chinese BIG5/Optional: Japanese font library, Korean KSC5601
Material specification
1.Media width (including liner paper): 79.5 ± 0.5 mm
2.Paper roll center size: None
3.Outer diameter of the paper roll: Up to 80mm
4.Paper thickness: 0.06 - 0.08 mm
5.Medium processing: Semi-cutting
6.Paper output method: Front-side output (for wall-mounted mode, it is rear-side output)
Power supply and money box
1.Sensor position: Middle
2.Support wall mounting:Yes
3.Power input: DC 24V 1.25A
4.Coin box output: DC 24V 1A
Physical parameters
1.Working environment: 0 - 45℃, 20% - 90% without condensation
2.Storage environment: -20 to 55℃, with no condensation at 20% to 93% humidity
3.Empty machine weight: 0.57 kg
4.Product dimensions (DxWxH): 155mm x 120mm x 100mm
5.Package dimensions (DxWxH): 225mm x 150mm x 120mm
Reliability
1.Print head wear resistance: 100 km
2.Blade life: 1 million cycles
Authentication method
1.Product certification methods: CCC, RoHS
Note：
1.The Bluetooth function requires an optional Bluetooth module, which is not included in the standard package.If you need Bluetooth connectivity, please select the Bluetooth version or contact our sales team before placing your order to ensure the correct configuration
2. The configurations and specifications listed on this page are subject to the actual products available in the market, and any changes will be made without prior notice.
