Print functionPrint functionPrint method: Line thermal printing
Point density: 203dpi × 203dpi
Printing speed: Maximum 300 millimeters per second *1
Interface standard model: USB-A/USB-B/USB-C (charging/communication)/Ethernet port/optional Wi-Fi wireless module ；Interface Bluetooth-Wi-Fi model: USB-A/USB-B/USB-C (charging/communication)/Ethernet port/Bluetooth/Wi-Fi
Interface data buffer: 4K
Print fontFont: English characters Font A 12x24; English characters Font B 10×24; English translation: 24×24
Character size (mm): English characters Font A 1.25 x 3.00 mm; English characters Font B 1.13 x 3.00 mm; English translation: 3.00 × 3.00 millimeters
Number of characters per line: 58 Width of paper in millimeters: 35/42 (Default) / 46; 80 mm paper width: 48 (Default) / 57 / 64
Character types: ANK A (default for 80mm), B (default for 58mm), C
Barcode Specifications: UPC-A, UPC-E, JAN8/EAN 8, JAN13/EAN13, Code39, Code93, Code128, Code128 Auto, ITF, CODABAR (NW-7), GS1-128, GS1 DataBar / QR Code, PDF417, Maxi Code, Data Matrix, Aztec, Two-dimensional GS1 DataBar, Composite Symbology
Paper size (mm)Width: 80 millimeters (79.5 +/- 0.5 millimeters) 58 millimeters (57.5 +/- 0.5 millimeters)
Diameter: 18 - 83 millimeters
Thickness: 0.048 - 0.08 millimeters
Electrical Specifications (mm)
Power supply device: PS-190
Power supply voltage: AC 100 to 230 V / 50 to 60 Hz
Power consumption: 30.6W during operation / 1.4W in standby mode
Safety standards
Safety standard: CCC
Reliability
Printer mechanism lifespan: 17 million times
Print head lifespan: 150 kilometers
Blade life: 2.2 million times
Average Fault-Free Operation Time: 360,000 hours
Average number of fault-free print runs: 65 million runs
Appearance
Dimensions (mm): Front paper exit 127mm (W) × 128mm (D) × 129mm (H) The paper size is 127mm (width) x 127mm (depth) x 130mm (height)
Operating environment
Temperature: Operation 5 - 45 °C / Storage 20 - 60 °C (excluding paper)
Humidity: Operating range 10% - 90% RH; Store at 19% - 90% RH (excluding paper)
A wireless module OT-WL06 is required as an optional accessory to enable Wi-Fi connection.
